Snow Melt Cable 120V, 4.17A, 43 ft.


Snow Melt Cable 120V, 4.17A, 43 ft.




Get an Instant Quote
Support Page

Features

  • High Heat Output: This embeddable electric heating cable provides 12-watts of heat per linear foot (nearly 50-watts per sq. ft.)

  • Embeddable in Concrete, Asphalt, or in Mortar Under Pavers: Installing a cable-based snow melting system within a new driveway, walkway, or patio means you can enjoy snow/ice free outdoor surfaces all year

  • Cost-Effective and Flexible: Snow melting cables are an less expensive (but more time consuming) alternative to snow melting mats and they provide maximum flexibility to cover round driveways, cornered patios, or outdoor stairs

  • Wide Variety of Voltages: We offer snow melting cables in 120, 208, 240, and 277 voltages and in a range of different lengths

  • Installation Support: WarmlyYours offers free SmartPlan™ installation plans, 24/7 phone support, and a 10-year limited warranty

Snow Melt Cables Description

WarmlyYours snow melting cable installs in asphalt, concrete or mortar under pavers. This 120 V twin conductor heating cable is perfect for open areas, as well as odd-shaped areas and stairways.

Each cable features a ¼” (6mm) twin-conductor heat resistant cable for energy efficient operation and generates 12 watts per lineal foot for dependable and efficient snow melting performance. This 43 ft. snow melting cable comes with 20 feet (6m) of 14 AWG cold lead. , making it ideal for smaller walkways and stoops.

All WarmlyYours snow melting cables are CSA certified for outdoor use in Canadian and U.S. markets.

Specifications

Electrical

Amps 4.17 A
Ohms 28.8 Ω
Voltage 120 V
Watts 500 W
Watts Per Linear Ft. 11.62 W
Watts Per Sq. Ft. at 3 Inch Spacing Up to 50
Watts Per Sq. Ft. at 4 Inch Spacing Up to 38.5
Watts Per Sq. Ft. at 5 Inch Spacing Up to 31.5

Warranty / Certifications

Approvals cCSAus Listed
Warranty 10 years

Performance

BTU Per Hour 1706 Btu

Product Dimensions

Cold Lead Length 20′
Coverage at 3 Inch Spacing 10.8 ft²
Coverage at 4 Inch Spacing 14.3 ft²
Coverage at 5 Inch Spacing 17.9 ft²
Heating Element Thickness 1/4″
Length 43′

Appearance

Color Green

Logistics

Country of Origin (COO) India

Cabling Specs

Ideal Cable Spacing 4″

Identifiers

SKU WHCA-120-0043
UPC (GTIN-12) 881308011260

Installation

Surface Types Asphalt, concrete or in mortar under pavers

Installation Plans

This is a real example of an installation plan that uses this product. If you want to design your own room or have any questions, please contact us.

Flooring
Concrete (new) Subfloor
N/A Voltage
208V Operating Cost
252 cents per hour

This Installation Plan Includes:


1 x
Snow Melt Cable 208V, 7.36A, 128 ft.
1 x
Snow Melt Cable 208V, 9.62A, 171 ft.
1 x
Snow Melt Cable 208V, 19.22A, 342 ft.

Customer Questions & Answers

Snow Melt Cables has 42 Questions and Answers.

Don't see the answer you're looking for? Post your question

How quickly do these systems melt the snow?

That depends on a number of variables (like the temperature outside) but generally speaking these snow melting systems are designed to melt 1" - 3" of snow per hour. Anything above 3" per hour is typically considered blizzard conditions.

22 people found this helpful.  Did you find this helpful? Yes No

Is it okay to cut the snow melting cable if it is too long for the application for which it was designed?

Never cut the heating cable. A heating cable will not work if it has been cut. If the heating cable is too long, call WarmlyYours to consult with a technician who will guide you in utilizing the additional length of cable.

17 people found this helpful.  Did you find this helpful? Yes No

How does the electric snow melting system compare to hot water tubing (hydronic) systems?

The material costs are similar. However, electric systems are easier to install, with fewer components and significantly lower maintenance costs. Electric systems will run for a shorter period of time to give the same level of performance but with much higher energy efficiency (typically 95%-98% efficient). Controls and sensors required for the two types of systems are very similar. Electric systems do not usually require slab insulation and do not create the concerns typically associated with hydronic systems. These concerns include, but are not limited to, return temperatures, flue gas venting, waterway shrinkage and property damage caused by leaking pipes or tubes.

14 people found this helpful.  Did you find this helpful? Yes No

May I cross or overlap the WarmlyYours snow melt heating cable?

When installing outdoor WarmlyYours snow melting cables for your driveway, patio, walkway, terrace, stairs, ramp, etc. - NEVER cross, overlap, or allow the heating cables to touch each other. Doing so will quickly cause a circuit failure due to excessive heat build up. Always follow the installation instructions and/or design layout plan to ensure the cable is installed with the correct spacing required for proper operation.

13 people found this helpful.  Did you find this helpful? Yes No

Does the factory splice need to be completely embedded during installation?

Yes. The manufacturer's splice that connects the heating element to the cold lead should be entirely embedded in a noncombustible material (like asphalt, concrete, or mortar) within the outdoor surface that is being heated.

12 people found this helpful.  Did you find this helpful? Yes No

View all 42 Questions and Answers

Customer Reviews

Snow Melt Cables achieved an average rating of 4.9 stars with 21 reviews by our customers.

Have you used this product before? Leave a review

Best service ever!

Marc C., Salt Lake City, UT on 10/19/2023

Mary was fantastic at listening and helping me find the best solution to melt ice and snow on my exterior stairs. Mary was kind and patient as this had many challenges and Mary worked through them all like a champ. We love our new system and love not shoveling.

Heating. Wire for driveway.

Vincent S., Wasaga Beach, ON on 06/07/2023

Easy to install, mostly because I have pavers on the driveway Your wiring looks very durable. My only concern is the exsesiers are very expensive. I had to look elsewhere for snow detectors for the unit. Otherwise I think your products are great.

Fantastic, knowledgeable, customer service

Jay R., Damascus, MD on 06/03/2023

Always a great experience with WarmlyYours. Efficient effective technology helps us with melting walkways and driveways as well as warming my feet in the bathroom etc.

Must have this if you live in a snowy region

Anonymous, Colorado Springs, CO on 01/03/2023

Works great! No more salt or shoveling!

No ice in front of the garage doors for the first time in years!

Anonymous, Leawood, KS on 05/06/2022

Our snow melting system was installed this fall and for the first time in years we did not have ice in front of the garage doors for weeks in the winter. The WarmlyYours staff were great to work with and answered our many questions with patience and knowledge.

Learning Curve

Scott R., Omaha, NE on 02/01/2022

There is definitely a learning curve but after that it was great to see the finished product working. Customer was extremely happy.

Your online and telephone support system is the greatest!

Bonnie P., Sterling, AK on 10/17/2021

We just finished laying in the wire and poured our cement, just a day before it started snowing-so we are curing the cement as I type. The men are now hooking up the electrical inside portions. The instructions have been so easy to follow step by step. I wanted to let you know it was so easy, I decided to do the one side of my garage with both systems to have a longer driveway of warmth/snow melt...because it was so cost effective that our family man-power did the labor. I plan on contacting you next Spring after the thaw to order up more wire, etc to do the smaller 14 foot section, which will be turned into a bedroom with a big front window I hope to enjoy looking out during the winter, instead of looking at by past 6 foot snow falling off my roof and building a wall I can't see through. I will send the end result after the electrical is finished plus a photo. :):)

Will have to wait and see!

Cwhr R., Morrison, CO on 06/18/2021

Only the wire is installed in the new walk. I will not be able to give a full review till next winter.

Just as advertised!

Cory W., Sidney, MT on 02/15/2021

We have only had the chance to use it during the last storm~not complaining about that at all. The heated sidewalk worked just as it had been represented. Melted the snow enough to make it easy to remove & when it froze later, turning the heat on for a few hours took care of it. Very happy with this purchase.

Problem finding a breaker for this system!

Paul B., Lake Zurich, IL on 02/15/2021

Having difficulty finding the appropriate beaker to run this system. Tech support at WarmlyYours says one thing and the supply house where you need to purchase the breaker says another (not available at local Home Depot or Menards). It would be nice if there were a part number, a suggested list of preferred vendors and an up front price range before making this purchase. The prices quoted for this breaker were between $200-$700 (for one breaker)...the entire sidewalk heating system was $1,000. Still cannot locate to correct breaker! Frustrating...

Response from WarmlyYours:

Paul, We are sorry to hear that you are not able to locate the correct breaker for your installation. The GFEP breaker type for outdoor heating is dictated by the National Electric Code and should be selected based on your breaker panel type/brand. For your installation, one 15 Amp 240V GFEP Circuit is required as indicated in the installation and electrical plan. Feel free to reach out to us with the brand of your breaker panel and we will do our best to assist you and find the right parts or direct you to the right place.
