How to Program Your Smartstat Thermostat
Master SmartStat Setup for Cozy, Efficient Heating
Ever dreamt of stepping onto warm floors on chilly mornings without spiking your energy bill? Experience the luxury of radiant heating with a SmartStat thermostat.
Our video guides you through programming your SmartStat thermostat to maximize comfort and efficiency. With this easy setup, you can enjoy warm floors exactly when you need them, whether it's for a cozy morning start or a warm welcome home after work. Our guide helps you save on energy costs while enhancing the quality of your indoor life.
In this video, you'll discover everything needed to effortlessly program your thermostat:
- 🔧 Easy faceplate removal and switch positioning for optimal display function
- 🗓️ Step-by-step guide to setting days and times for precise heating control
- 🕒 Programming up to four warming periods daily for tailored comfort
- 🌡️ Customizing comfort and economy temperatures to suit your lifestyle
- 📞 Access to expert support for personalized thermostat setup
By following these straightforward steps, you'll transform your home into a haven of warmth and efficiency. Take control of your comfort and watch the video to learn how to harness the full potential of your SmartStat thermostat.
Transcript
Remove the faceplate from the base unit and locate the three switches on the rear of the faceplate to ensure proper operation of the display and the floor warming system. All three switches should be in the UP position before refitting the faceplate. Next, open the side panels on the thermostat and turn the standby switch to the ON position. Press the Day button as many times as necessary to set the thermostat to the correct day, and then use the Hour and Minute buttons to set the correct time. PM hours will be indicated with "PM" to the left of the time, while AM hours will not have such an annotation.
Unless you intend to maintain the same temperature continuously, you will need to set up warming periods. The thermostat allows for programming up to four periods per day by default. For weekdays, this thermostat is configured to perform two warming periods: the first from 6 AM to 8:30 AM and the second from 5 PM to 11 PM. On Saturdays and Sundays, only one warming period is set, running from 6 AM to 11 PM. To modify this schedule, enter the programming mode by pressing the Program button. The screen will display a house icon with the number one inside, indicating the start of the first warming period.
To program the same settings for every day of the week, press and hold the Day button for three seconds, which will cause all seven days to appear on the screen. Use the Hour and Minute buttons to select the start time of the first warming period, which is set to 6 AM by default. After setting the start time, press the Program button to display the second house icon with the number two inside. If you only require one period each day, you can skip this setting by pressing the Clear button. Next, use the Hour and Minute buttons to select the end time of the first warming period, which defaults to 8:30 AM.
Press the Program button again to show the third house icon with the number three inside. If you only need one warming period each day, you can skip this setting as well by pressing the Clear button. Use the Hour and Minute buttons to select the start time of the second warming period, which defaults to 5 PM. Press the Program button once more to display the fourth house icon with the number four inside. Finally, use the Hour and Minute buttons to select the end time of the second heating period, which is set to 11 PM by default.
To complete the programming, press the Mode Return button, which will show the clock icon, indicating that the thermostat is now in automatic mode. During the programmed periods, the thermostat will operate at the comfort temperature, while between these periods, it will revert to the economy temperature. The default comfort setting is a floor temperature of 82 degrees Fahrenheit. To modify this temperature, use the up and down buttons to reach your desired setting, then press and hold the Comfort button for three seconds. After five seconds, the current floor temperature will be displayed again.
The default economy setting is a floor temperature of 68 degrees Fahrenheit. Similar to the comfort setting, you can modify this temperature by using the up and down buttons, followed by pressing and holding the Economy button for three seconds. After another five seconds, the current floor temperature will be displayed. Generally, a preferred comfort temperature ranges between 80 and 85 degrees Fahrenheit. If you select an economy temperature significantly lower than the comfort temperature, the thermostat will take longer to reach the desired comfort level. However, an economy temperature set between 70 and 75 degrees Fahrenheit will allow the thermostat to return to comfort quickly while using relatively little electricity.
Every installation is unique due to variations in subflooring, flooring materials, insulation, and individual comfort levels. Therefore, it is essential for the end user to determine their most favorable settings. The thermostat can be switched between manual and automatic modes by pressing the Mode Return button. Manual mode is indicated by a hand icon, while automatic mode is represented by a clock icon. It is important to note that time and temperature settings will only be respected in automatic mode. In manual mode, the thermostat will maintain a constant temperature at whatever level it has been set using the up or down buttons. For more information or personalized assistance in setting your thermostat, please call WarmlyYours at 800-875-528.
Retirez la façade de l'unité de base et localisez les trois interrupteurs à l'arrière de la façade pour assurer le bon fonctionnement de l'écran et du système de chauffage au sol. Les trois interrupteurs doivent être en position UP avant de remettre la façade en place. Ensuite, ouvrez les panneaux latéraux du thermostat et placez l'interrupteur de veille en position ON. Appuyez sur le bouton Day autant de fois que nécessaire pour régler le thermostat sur le jour correct, puis utilisez les boutons Hour et Minute pour régler l'heure correcte. Les heures PM sont indiquées par "PM" à gauche de l'heure, tandis que les heures AM n'ont pas cette annotation.
Si vous n'avez pas l'intention de maintenir la même température en permanence, vous devrez programmer des périodes de réchauffement. Par défaut, le thermostat permet de programmer jusqu'à quatre périodes par jour. En semaine, ce thermostat est configuré pour effectuer deux périodes de chauffage : la première de 6h à 8h30 et la seconde de 17h à 23h. Les samedis et dimanches, une seule période de chauffage est programmée, de 6h à 23h. Pour modifier cet horaire, entrez dans le mode de programmation en appuyant sur le bouton Programme. L'écran affichera une icône de maison avec le chiffre 1 à l'intérieur, indiquant le début de la première période de chauffe.
Pour programmer les mêmes paramètres pour chaque jour de la semaine, appuyez sur la touche Day pendant trois secondes, ce qui fera apparaître les sept jours à l'écran. Utilisez les touches Hour et Minute pour sélectionner l'heure de début de la première période de chauffe, qui est réglée par défaut sur 6 heures du matin. Après avoir réglé l'heure de début, appuyez sur la touche Programme pour afficher l'icône de la deuxième maison avec le chiffre deux à l'intérieur. Si vous n'avez besoin que d'une seule période par jour, vous pouvez ignorer ce réglage en appuyant sur le bouton Clear (Effacer). Ensuite, utilisez les touches Hour et Minute pour sélectionner l'heure de fin de la première période de chauffe, qui est par défaut fixée à 8h30.
Appuyez à nouveau sur le bouton Programme pour afficher l'icône de la troisième maison avec le chiffre trois à l'intérieur. Si vous n'avez besoin que d'une seule période de chauffe par jour, vous pouvez également ignorer ce réglage en appuyant sur la touche Clear. Utilisez les touches Hour et Minute pour sélectionner l'heure de début de la deuxième période de chauffe, qui est par défaut fixée à 17 heures. Appuyez une nouvelle fois sur la touche Programme pour afficher l'icône de la quatrième maison avec le chiffre quatre à l'intérieur. Enfin, utilisez les touches Heure et Minute pour sélectionner l'heure de fin de la deuxième période de chauffe, qui est réglée par défaut sur 23 heures.
Pour terminer la programmation, appuyez sur le bouton Retour au mode, qui affichera l'icône de l'horloge, indiquant que le thermostat est maintenant en mode automatique. Pendant les périodes programmées, le thermostat fonctionne à la température de confort, tandis qu'entre ces périodes, il revient à la température d'économie. Le réglage de confort par défaut est une température de plancher de 82 degrés Fahrenheit. Pour modifier cette température, utilisez les boutons haut et bas pour atteindre le réglage souhaité, puis appuyez sur le bouton Comfort pendant trois secondes. Au bout de cinq secondes, la température actuelle du plancher s'affiche à nouveau.
Le réglage économique par défaut est une température de 68 degrés Fahrenheit. Comme pour le réglage de confort, vous pouvez modifier cette température en utilisant les boutons haut et bas, puis en appuyant sur le bouton Économie et en le maintenant enfoncé pendant trois secondes. Après cinq secondes supplémentaires, la température actuelle du plancher s'affiche. En général, une température de confort préférée se situe entre 80 et 85 degrés Fahrenheit. Si vous sélectionnez une température économique nettement inférieure à la température de confort, le thermostat mettra plus de temps à atteindre le niveau de confort souhaité. Cependant, une température économique réglée entre 70 et 75 degrés Fahrenheit permettra au thermostat de revenir rapidement au niveau de confort tout en consommant relativement peu d'électricité.
Chaque installation est unique en raison des variations de la sous-couche, des matériaux de revêtement de sol, de l'isolation et des niveaux de confort individuels. Il est donc essentiel que l'utilisateur final détermine ses réglages les plus favorables. Le thermostat peut passer du mode manuel au mode automatique en appuyant sur le bouton de retour au mode. Le mode manuel est indiqué par une icône de main, tandis que le mode automatique est représenté par une icône d'horloge. Il est important de noter que les réglages de l'heure et de la température ne seront respectés qu'en mode automatique. En mode manuel, le thermostat maintiendra une température constante, quel que soit le niveau réglé à l'aide des boutons haut et bas. Pour plus d'informations ou une assistance personnalisée dans le réglage de votre thermostat, veuillez appeler WarmlyYours au 800-875-528.
Retire la placa frontal de la unidad base y localice los tres interruptores de la parte posterior de la placa frontal para garantizar el correcto funcionamiento de la pantalla y del sistema de calentamiento del suelo. Los tres interruptores deben estar en la posición ARRIBA antes de volver a colocar la placa frontal. A continuación, abra los paneles laterales del termostato y coloque el interruptor de espera en la posición ON. Pulse el botón Day tantas veces como sea necesario para ajustar el termostato al día correcto y, a continuación, utilice los botones Hour y Minute para ajustar la hora correcta. Las horas PM se indicarán con "PM" a la izquierda de la hora, mientras que las horas AM no tendrán tal anotación.
A menos que pretenda mantener la misma temperatura continuamente, necesitará establecer periodos de calentamiento. Por defecto, el termostato permite programar hasta cuatro periodos por día. Para los días laborables, este termostato está configurado para realizar dos periodos de calentamiento: el primero de 6 AM a 8:30 AM y el segundo de 5 PM a 11 PM. Los sábados y domingos, sólo se configura un periodo de calentamiento, de 6 AM a 11 PM. Para modificar este horario, acceda al modo de programación pulsando el botón Programar. La pantalla mostrará el icono de una casa con el número uno en su interior, indicando el inicio del primer periodo de calentamiento.
Para programar los mismos ajustes para todos los días de la semana, mantenga pulsado el botón Día durante tres segundos, lo que hará que aparezcan los siete días en la pantalla. Utilice los botones Hora y Minuto para seleccionar la hora de inicio del primer periodo de calentamiento, que por defecto está ajustada a las 6 AM. Después de ajustar la hora de inicio, pulse el botón Programar para que aparezca el icono de la segunda casa con el número dos dentro. Si sólo necesita un periodo cada día, puede omitir este ajuste pulsando el botón Borrar. A continuación, utilice los botones Hora y Minuto para seleccionar la hora de finalización del primer periodo de calentamiento, que por defecto es a las 8:30 AM.
Pulse de nuevo el botón Programar para mostrar el icono de la tercera casa con el número tres en su interior. Si sólo necesita un periodo de calentamiento al día, puede omitir también este ajuste pulsando el botón Borrar. Utilice los botones Hora y Minuto para seleccionar la hora de inicio del segundo periodo de calentamiento, que por defecto es a las 5 PM. Pulse el botón Programa una vez más para visualizar el icono de la cuarta casa con el número cuatro en su interior. Por último, utilice los botones Hora y Minuto para seleccionar la hora de finalización del segundo periodo de calentamiento, que por defecto está fijada en las 23 horas.
Para finalizar la programación, pulse el botón Modo Retorno, que mostrará el icono del reloj, indicando que el termostato se encuentra ahora en modo automático. Durante los periodos programados, el termostato funcionará a la temperatura de confort, mientras que entre estos periodos, volverá a la temperatura de ahorro. El ajuste de confort por defecto es una temperatura de suelo de 82 grados Fahrenheit. Para modificar esta temperatura, utilice los botones arriba y abajo hasta alcanzar el ajuste deseado y, a continuación, mantenga pulsado el botón Confort durante tres segundos. Transcurridos cinco segundos, volverá a mostrarse la temperatura actual del suelo.
El ajuste económico predeterminado es una temperatura del suelo de 68 grados Fahrenheit. De forma similar al ajuste de confort, puede modificar esta temperatura utilizando los botones arriba y abajo, seguido de mantener pulsado el botón Economía durante tres segundos. Después de otros cinco segundos, se mostrará la temperatura actual del suelo. Generalmente, una temperatura de confort preferida oscila entre 80 y 85 grados Fahrenheit. Si selecciona una temperatura económica significativamente inferior a la temperatura de confort, el termostato tardará más tiempo en alcanzar el nivel de confort deseado. Sin embargo, una temperatura económica ajustada entre 70 y 75 grados Fahrenheit permitirá que el termostato vuelva al nivel de confort rápidamente, a la vez que consume relativamente poca electricidad.
Cada instalación es única debido a las variaciones en el subsuelo, los materiales del suelo, el aislamiento y los niveles de confort individuales. Por lo tanto, es esencial que el usuario final determine sus ajustes más favorables. El termostato puede conmutarse entre los modos manual y automático pulsando el botón de retorno de modo. El modo manual se indica mediante el icono de una mano, mientras que el modo automático se representa mediante el icono de un reloj. Es importante tener en cuenta que los ajustes de hora y temperatura sólo se respetarán en modo automático. En modo manual, el termostato mantendrá una temperatura constante en el nivel que se haya ajustado mediante los botones arriba o abajo. Para obtener más información o asistencia personalizada para ajustar su termostato, llame a WarmlyYours al 800-875-528.
Zdejmij płytę czołową z jednostki bazowej i zlokalizuj trzy przełączniki z tyłu płyty czołowej, aby zapewnić prawidłowe działanie wyświetlacza i systemu ogrzewania podłogowego. Przed ponownym założeniem płyty czołowej wszystkie trzy przełączniki powinny znajdować się w pozycji UP. Następnie otwórz panele boczne termostatu i ustaw przełącznik trybu gotowości w pozycji ON. Naciśnij przycisk Day tyle razy, ile potrzeba, aby ustawić termostat na właściwy dzień, a następnie użyj przycisków Hour i Minute, aby ustawić prawidłowy czas. Godziny PM będą oznaczone napisem "PM" po lewej stronie godziny, podczas gdy godziny AM nie będą miały takiej adnotacji.
Jeśli nie zamierzasz utrzymywać tej samej temperatury przez cały czas, musisz ustawić okresy ogrzewania. Termostat domyślnie umożliwia zaprogramowanie do czterech okresów na dzień. W dni powszednie termostat jest skonfigurowany do wykonywania dwóch okresów ogrzewania: pierwszego od 6:00 do 8:30 i drugiego od 17:00 do 23:00. W soboty i niedziele ustawiony jest tylko jeden okres ogrzewania, trwający od 6 rano do 11 wieczorem. Aby zmodyfikować ten harmonogram, należy przejść do trybu programowania, naciskając przycisk Program. Na ekranie zostanie wyświetlona ikona domu z cyfrą jeden w środku, wskazująca początek pierwszego okresu ogrzewania.
Aby zaprogramować te same ustawienia dla każdego dnia tygodnia, naciśnij i przytrzymaj przycisk Day (Dzień) przez trzy sekundy, co spowoduje wyświetlenie na ekranie wszystkich siedmiu dni. Za pomocą przycisków Godzina i Minuta wybierz godzinę rozpoczęcia pierwszego okresu ogrzewania, która domyślnie ustawiona jest na 6 rano. Po ustawieniu godziny rozpoczęcia naciśnij przycisk Program, aby wyświetlić ikonę drugiego domu z cyfrą dwa w środku. Jeśli wymagany jest tylko jeden okres każdego dnia, można pominąć to ustawienie, naciskając przycisk Clear (Wyczyść). Następnie użyj przycisków Godzina i Minuta, aby wybrać godzinę zakończenia pierwszego okresu ogrzewania, która domyślnie ustawiona jest na 8:30 rano.
Ponownie naciśnij przycisk Program, aby wyświetlić ikonę trzeciego domu z cyfrą trzy w środku. Jeśli potrzebny jest tylko jeden okres ogrzewania każdego dnia, można pominąć to ustawienie, naciskając przycisk Clear (Wyczyść). Za pomocą przycisków Godzina i Minuta wybierz godzinę rozpoczęcia drugiego okresu ogrzewania, która domyślnie ustawiona jest na 17:00. Ponownie naciśnij przycisk Program, aby wyświetlić ikonę czwartego domu z cyfrą cztery w środku. Na koniec użyj przycisków Godzina i Minuta, aby wybrać godzinę zakończenia drugiego okresu ogrzewania, która domyślnie ustawiona jest na 23:00.
Aby zakończyć programowanie, naciśnij przycisk powrotu do trybu, który wyświetli ikonę zegara, wskazując, że termostat jest teraz w trybie automatycznym. Podczas zaprogramowanych okresów termostat będzie działał w temperaturze komfortowej, a pomiędzy tymi okresami powróci do temperatury ekonomicznej. Domyślnym ustawieniem komfortowym jest temperatura podłogi wynosząca 82 stopnie Fahrenheita. Aby zmodyfikować tę temperaturę, użyj przycisków w górę i w dół, aby osiągnąć żądane ustawienie, a następnie naciśnij i przytrzymaj przycisk Komfort przez trzy sekundy. Po pięciu sekundach ponownie wyświetlona zostanie bieżąca temperatura podłogi.
Domyślnym ustawieniem ekonomicznym jest temperatura podłogi wynosząca 68 stopni Fahrenheita. Podobnie jak w przypadku ustawienia komfortowego, temperaturę tę można zmienić za pomocą przycisków w górę i w dół, a następnie naciskając i przytrzymując przycisk ekonomiczny przez trzy sekundy. Po kolejnych pięciu sekundach wyświetlona zostanie aktualna temperatura podłogi. Ogólnie rzecz biorąc, preferowana temperatura komfortowa wynosi od 80 do 85 stopni Fahrenheita. W przypadku wybrania temperatury ekonomicznej znacznie niższej niż temperatura komfortowa, termostat będzie potrzebował więcej czasu, aby osiągnąć żądany poziom komfortu. Jednak temperatura ekonomiczna ustawiona między 70 a 75 stopni Fahrenheita pozwoli termostatowi szybko powrócić do komfortu przy stosunkowo niewielkim zużyciu energii elektrycznej.
Każda instalacja jest unikalna ze względu na różnice w podłożu, materiałach podłogowych, izolacji i indywidualnym poziomie komfortu. Dlatego ważne jest, aby użytkownik końcowy określił swoje najkorzystniejsze ustawienia. Termostat można przełączać między trybem ręcznym i automatycznym, naciskając przycisk powrotu trybu. Tryb ręczny jest oznaczony ikoną dłoni, a tryb automatyczny ikoną zegara. Należy pamiętać, że ustawienia czasu i temperatury będą przestrzegane tylko w trybie automatycznym. W trybie ręcznym termostat będzie utrzymywał stałą temperaturę na poziomie ustawionym za pomocą przycisków w górę lub w dół. Aby uzyskać więcej informacji lub spersonalizowaną pomoc w ustawieniu termostatu, prosimy o kontakt z WarmlyYours pod numerem 800-875-528.
