Replacement/Backup Floor Sensor with Standard Sensor Probe
This 10k ohms replacement/backup floor sensor, with a standard sensor probe, works with all floor heating controls available from WarmlyYours, including the nSpiration Series. It’s compatible with a wide variety of floor heating thermostats and it works to accurately sense the temperature reading of radiant floors while operating in a floor-sensing or ambient-sensing/floor-limiting mode. The 15-foot cable offers enough length for optimal thermostat positioning in your room.
Please note that every WarmlyYours thermostat already comes with a complimentary 10k ohms floor sensor.
Documents & Manuals
- Slab Heat Wiring Diagram for TH115, TH114 and a Relay (English)
- Slab Heat Wiring Diagram for TH115, TH114, Power Module (English)
- TempZone™ Custom & Standard Mat Wiring Diagram (English)
- WIRING DIAGRAM 120V & 240V Heating Products with PB112D-GA (English)
- Wiring Diagram for TempZone™ Cut & Turn Single Conductor (Multiple rolls) 120V & 240V with SmartStat™, EasyStat™ and Comfort Regulator (English)
- Wiring Diagram for TempZone™ Cut & Turn Twin Conductor (Multiple Rolls) 120V & 240V with SmartStat™, EasyStat™, Comfort Regulator and Power Modules (English)
Customer Questions & Answers
Installation and Repair Parts has 21 Questions and Answers.
How do I work with my electrician to install WarmlyYours electric floor heating?
While WarmlyYours electric radiant floor heating systems are typically installed by your floor covering contractor, a licensed electrician is recommended for the final thermostat hook-up. With every quote, we provide an Installation Plan layout, together with an electrical plan that has all the info required for the electrician.
How can I determine what I need for my floor heating project and how can I find out what my floor heating system will cost?
You can use the Instant Quote Tool, which gives you many options for your floor heating coverage. Use this interactive tool to design your room online and receive an instant quotation with product recommendations, rough-in and installation kits, cost of your control, etc. Planning your floor heating project is made easy when using our Instant Quote Tool.
Send us your floor plan or fax it to (800) 408-1100 and we will send you a quote, product recommendation and a free custom installation plan for your project.
What type of flooring can I install along with an electric floor heating system?
WarmlyYours’ TempZone™ product is most commonly installed under tile, stone, and marble flooring, but can also be installed under many other popular floor covering options such as hardwood, vinyl and linoleum. We also have our Environ system, which is an electric floor heating product as well and is specially designed for installation under carpet (in the U.S. only), laminate and floating wood. WarmlyYours can accommodate any flooring type with either of the electric radiant floor heating products that we offer. If your flooring type isn't listed here, just give us a call at (800) 875-5285 and we will be happy to discuss it with you.
If I have extra cold lead wire, can I trim off what I don't need for my installation?
Yes. Unlike the heating cable for electric floor heating, the cold lead wires can be trimmed or lengthened with additional lead wire which can be purchased from WarmlyYours.
How do I know if I am installing my electric floor heating system properly?
Please keep in mind that you must check your electric floor heating system with a digital ohmmeter in conjunction with a Circuit Check™. Take an initial reading as soon as you take the product out of the box to verify that it is within -5% / +10% of the values stated on the product’s label. This will give you a basis of comparison for future readings. Take a second reading once you have positioned the system to match your custom installation plan. It is also advisable to take an additional reading in the middle of the tile installation, just to make sure that the Circuit Check™ is doing its job. Then, take a final reading when you are finished with the floor installation and are ready to hook up the thermostat.
The Circuit Check™ is a tool developed by WarmlyYours to give you peace of mind and ensure trouble-free installations. Simply hook up the cold leads to the tool while you position the system to match your custom installation plan.
The Circuit Check™ will continuously monitor the continuity of the circuit during the installation of your system and during the installation of your flooring. The Circuit Check™ beeps immediately when a short in the system is detected, alerting you to a potentially damaged cable in the area you are working, before you lay the tile over the electric floor heating system. The WarmlyYours technical support team is available 24/7 to provide assistance if the alarm sounds, or if you would have any questions during your installation.
View all 21 Questions and Answers
Installation and Repair Parts achieved an average rating of 4.9 stars with 25 reviews by our customers.
Wish we did it 15 years ago
Questar W., Riverhead, NY on 04/18/2022
Adding the radiant heat to our bathroom floor was the best improvement we have done in out house in years. It changed our late night winter trips to the bathroom. The floor was always freezing and even stepping out of the shower was a shock to the senses. Now its a pleasure to feel the warmth. The customer support is very helpful and thorough which is rare today. I had a condition where the floor would not go above 83 and I assumed there was a problem with the install. I spoke with a rep for a long while about this problem. An hour later i received a call advising me to check if the thermostat was set to laminate flooring instead of tile. It was. Problem solved. I highly recommend WarmlyYours if you are considering radiant flooring.
Great product and customer service
Prometheusbuilders, Minnetonka, MN on 04/09/2022
The floor heating cable was simple to install and works great. Troy’s customer service was awesome as always and the turnaround time on his floor layout was very prompt. Delivery of the heat cable and thermostat was very fast also, only took a couple days.
Thomas C., Garden City, NY on 01/18/2022
I really appreciated the dicount given for a return customer. The mat came in a little smaller than I was expecting based on the drawings but in the end it all worked out fine and the floor is nice an warm.
Not as intimidating as I thought
Anonymous, Hampton, NH on 12/15/2021
Worked with Justin throughout the process and things went very well. Even though there were a few mistakes on my part we were able to work through them. Be sure your layout you provide is accurate!! Submitted a diagram of my new bathroom layout and received the plan for how to layout the mats. After paying, received the kit and instructions. Pretty much follow the instructions. If you are a DIY person with a bit of electric know-how, this is fairly easy. Things to look out for - be sure to use the squawker when laying the mat to assure you don't break it. Have a decent glue gun to hold down any wires when you have to work around something. You can also use the gun to stick the mat better to the floor. An open wall makes the wiring go a lot easier. Otherwise, you need to be proficient in snaking a wire through a wall. The only hiccup was the electric box provided. The thermostat does not fit easily; an extremely tight fit to the point that without a lot of force, I couldn't get it to fit before even trying to install it. Right out of the box, things did not fit easily. There are better and larger plastic boxes you can get at Home Depot or Lowes. It needs to be LONG not wide. My suggestion to WarmlyYours is provide a bigger box or give an option to exclude the package sold without the electric box pieces. All in all - worth the price and the effort.
Very good product. Easy installation.
Anonymous, Denville, NJ on 12/04/2021
Very good product. Easy installation.
Michael C., Oak Park, IL on 11/24/2021
Yves B., L'ancienne Lorette, QC on 09/07/2021
Very fast delevery
Every online purchase experience should be this great!
Cliff H., Durango, CO on 08/09/2021
Outstanding support every step of the way. Customized installation plan based on the floor plan I provided made the installation process a breeze. I received a note from the support team shortly after the product was delivered, but I never needed to reach out to them because it was all so well documented. I just installed the thermostat today, and it was easy to set up and use. Looking forward to some cool weather so I can really appreciate the warm bathroom floor.
Seems like inexpensive insurance
Cliff H., Durango, CO on 08/09/2021
Since the thermostat requires an infloor sensor, having a backup installed seems like a smart move.
Everything was perfect
Doug H., Rochester, NY on 08/08/2021
I do many bathroom jobs as I am a general contractor. I always use your products because they are the best! The technical services are the best. My salesperson ( Mary Godawa ) is a professional, individual who is a very helpful pleasure to deal with!
