Ember Glass Radiant Panel Heater - Black - 800W - 47ʺ x 24ʺ - Dual Connection
What Size Panel Do I Need?
A radiant heat panel is a great way to add supplemental heat to a room—not unlike a wall mounted space heater. The table below will help you identify the typical room size* that a radiant heat panel can help warm up, based on wattage/heat output.
| Radiant Panel Wattage* | Warming Coverage |
|---|---|
| 300W Ember | 43 sq. ft. |
| 500W Ember | 71 sq. ft. |
| 600W Ember (Glass Only) | 86 sq. ft. |
| 700W Ember | 100 sq. ft. |
| 800W Ember (Glass Only) | 114 sq. ft. |
*This estimation is based on installing a radiant panel in a typical/average room. One factor that will impact the actual results is a room's degree of heat loss, which can be impacted by a number of factors including ceiling height, number of windows, and insulation level.
To get a free Heat Loss Calculation based on your room:
Features
-
Wall mounted: this 47” x 24” infrared heating panel can be installed vertically or horizontally on your wall
-
High heat output: this panel heater delivers an impressive heat output of 2,728 BTUs per hour
-
Energy efficient: it only costs approximately 8 cents per hour on average to run this electric wall heater
-
Dual connection: can be hardwired to a thermostat or plug-in a standard outlet (120 VAC)
-
Covered by a 5-year limited warranty
Ember Glass Radiant Panels Description
Taking its name from the aftereffects of a fire, Ember radiant panels emit heat without a flame. In fact, they emit enough heat to act as a primary or supplementary heating source for a room. Unlike convection heating, this 3.9- by 2-foot black panel heats the surfaces and objects in a room instead of the air. This allows the warmth to be stored longer within the materials before being released slowly and evenly into the air. As a result, the ambient air temperature will be cooler, but those in the room will feel warmer. To deliver even heat, the panels can be mounted to a wall. These radiant panels benefit allergy sufferers because they do not circulate dust or other allergens into the air. They can also be used as towel warmers when towel bars are attached to a vertically mounted panel located in a dry area of your bathroom. Plus, they are unique in that that they have one of the highest possible efficiency rates and consume the least amount of energy possible*.
These panels are also dual connection, meaning they can be used “as is” to plug into a standard 120 VAC outlet or they can be modified by a licensed electrician to have a hardwired 120 VAC electrical connection.
Note: Towel bars must be purchased separately.
* Infrapower Manufacturing Ltd.
Features:
- Wall Mounted: This 47” x 24” radiant panel can be installed vertically or horizontally on your wall
- Dual Connection: Can be hardwired to a thermostat or plug-in a standard outlet (120 VAC)
- High Heat Output: This infrared heating panel puts out 2,728 BTUs per hour
- Low Operating Cost: It only costs roughly $0.10 per hour to run this model (based on a national average electrical cost of 12 cents per kWh)
- Safe and Stylish: This radiant panel is not only more aesthetically pleasing than a propane space heater but it’s also safer
- 5-year Warranty: This product is covered by a 5-year limited warranty
Specifications
Electrical
| Amps | 6.7 A |
| Connection Method | Plug-in or Hardwired |
| Cord Length | 6′ |
| Ohms | 17.91 Ω |
| On/Off Switch | No |
| Plug-Type | NEMA 5-15 (Type B) |
| Thermal Power | 0.8 kW |
| Voltage | 120 V |
| Watts | 800 W |
Warranty / Certifications
| Approvals | cTUVus certified |
| Ingress Protection (IPxx) Rating | IP65 |
| RoHS Compliance | 2002/95/EC (RoHS 1) |
| Warranty | 5 years |
Performance
| Average Surface Temperature | 194 °F |
| BTU Per Hour | 2730 Btu |
| Heating Coverage | 114 ft² |
| Surface Safety Limit | 248 °F |
Product Dimensions
| Depth | 1.5″ |
| Depth with Towel Bar Accessory | 4.5″ |
| Height | 47.2″ |
| Length | 47.2″ |
| Weight | 40.7 lbs |
| Width | 23.6″ |
Appearance
| Finish | Glass Black |
| Model | Ember Glass Black - 47″ x 24″ |
| Size | 47″ x 24″ - 800W |
Installation
| Mounting Locations | Wall |
| Mounting Orientation | Horizontal or Vertical |
Identifiers
| SKU | IP-EM-GLS-BLK-0800 |
| UPC (GTIN-12) | 881308039165 |
