Tech Tips: Environ Floor Heating Sensor Placement
Master Sensor Placement for Optimal Heating Efficiency
Are you struggling to achieve consistent warmth with your floor heating system? Correct sensor placement is crucial to ensuring your floors heat evenly and efficiently.
This video provides a detailed walkthrough on how to position sensors in Environ 2 floor heating panels for optimal performance. By following these expert tips, you can enjoy a cozy home without skyrocketing energy bills.
Dive into our guide to learn how to position your sensors for the best results:
- 💡 Ensure precise sensor head placement between heating wires for accurate temperature readings.
- 📍 Discover the best technique for securing the sensor using tape to prevent displacement.
- 🏠 Learn how to correctly insert and manage cables under the carpet pad for a seamless installation.
- 🔧 Follow our advice to mark, cut, and position the sensor head effectively within the mat structure.
By mastering these proven techniques, you can transform your space into a haven of warmth and comfort. Watch the video now and embrace the luxurious warmth of radiant heating with your Electric Floor Heating System. Experience the benefits of energy-efficient heating and elevate your home's ambiance today!
Transcript
Today, we're going to discuss sensor placement when installing Environnn 2 panels. If you examine the Environnn 2 panel, you'll notice the raised areas where my fingers are positioned; this is where the actual heating wire is located, nestled between the aluminum open area. The objective is to position the sensor head midway between each heating wire. According to the installation manual, you can simply tape it to the top or underneath in the same location. However, we have discovered a more effective method that operates slightly more efficiently and yields better heating results.
To achieve optimal placement, you should locate the sensor approximately six inches into the mat. Once you've identified this location, ensure that the sensor head is positioned correctly. We recommend marking this spot with your finger for reference. Next, take a small section of the carpet pad out, roughly the size of a corner, and verify that this area is situated between one of the two runs of cable. At this point, you have two options: you can either place the sensor head directly into the hole you created or, if you're near the edge of the wall, you can insert the sensor and run the cable underneath the pad.
If you choose to run the cable under the pad, you can secure it in place with tape as it enters the hole. Additionally, using a piece of tape to hold the sensor in position will ensure that when you lay down the mat, it rests correctly in the middle of the designated area. Once everything is set, you can pull your carpet over that section, confident that you'll achieve an accurate temperature reading in that spot.
Aujourd'hui, nous allons parler de l'emplacement des capteurs lors de l'installation des panneaux Environnn 2. Si vous examinez le panneau Environnn 2, vous remarquerez les zones surélevées où mes doigts sont positionnés ; c'est là que se trouve le fil chauffant réel, niché entre la zone ouverte en aluminium. L'objectif est de positionner la tête du capteur à mi-chemin entre chaque fil chauffant. D'après le manuel d'installation, vous pouvez simplement la coller sur le dessus ou en dessous, au même endroit. Cependant, nous avons découvert une méthode plus efficace qui fonctionne un peu mieux et donne de meilleurs résultats de chauffage.
Pour obtenir un positionnement optimal, vous devez placer le capteur à environ six pouces dans le tapis. Une fois que vous avez identifié cet emplacement, assurez-vous que la tête du capteur est correctement positionnée. Nous vous recommandons de marquer cet endroit avec votre doigt pour référence. Ensuite, retirez une petite section du tapis, de la taille d'un coin, et vérifiez que cette zone est située entre l'un des deux câbles. À ce stade, deux possibilités s'offrent à vous : vous pouvez placer la tête du capteur directement dans le trou que vous avez créé ou, si vous êtes près du bord du mur, vous pouvez insérer le capteur et faire passer le câble sous la moquette.
Si vous choisissez de faire passer le câble sous le coussin, vous pouvez le fixer avec du ruban adhésif lorsqu'il pénètre dans le trou. En outre, l'utilisation d'un morceau de ruban adhésif pour maintenir le capteur en position permet de s'assurer que lorsque vous posez le tapis, il repose correctement au milieu de la zone désignée. Une fois que tout est en place, vous pouvez poser votre tapis sur cette section, en étant sûr d'obtenir une mesure précise de la température à cet endroit.
Hoy vamos a hablar de la colocación de los sensores al instalar los paneles Environnn 2. Si examina el panel Environnn 2, observará las zonas elevadas donde están colocados mis dedos; aquí es donde se encuentra el cable calefactor real, encajado entre la zona abierta de aluminio. El objetivo es colocar el cabezal del sensor a medio camino entre cada cable calefactor. Según el manual de instalación, puede simplemente pegarlo en la parte superior o inferior en el mismo lugar. Sin embargo, hemos descubierto un método más eficaz que funciona de forma ligeramente más eficiente y produce mejores resultados de calentamiento.
Para lograr una colocación óptima, debe situar el sensor a unos 15 cm dentro de la alfombrilla. Una vez que haya identificado esta ubicación, asegúrese de que el cabezal del sensor esté colocado correctamente. Le recomendamos que marque este punto con el dedo como referencia. A continuación, retire una pequeña sección de la alfombrilla, aproximadamente del tamaño de una esquina, y compruebe que esta zona está situada entre uno de los dos tramos de cable. En este punto, tienes dos opciones: puedes colocar el cabezal del sensor directamente en el orificio que has creado o, si estás cerca del borde de la pared, puedes insertar el sensor y pasar el cable por debajo del acolchado.
Si optas por pasar el cable por debajo de la almohadilla, puedes fijarlo con cinta adhesiva cuando entre en el orificio. Además, si utiliza un trozo de cinta adhesiva para sujetar el sensor en su posición, se asegurará de que cuando coloque la alfombrilla, ésta descanse correctamente en el centro de la zona designada. Una vez que todo esté colocado, puede extender la alfombra sobre esa sección, con la seguridad de que obtendrá una lectura precisa de la temperatura en ese lugar.
Dzisiaj omówimy rozmieszczenie czujników podczas instalacji paneli Environnn 2. Jeśli przyjrzysz się panelowi Environnn 2, zauważysz uniesione obszary, w których umieszczone są moje palce; w tym miejscu znajduje się rzeczywisty przewód grzejny, umieszczony między aluminiową otwartą powierzchnią. Celem jest umieszczenie głowicy czujnika w połowie odległości między każdym przewodem grzejnym. Zgodnie z instrukcją instalacji, można po prostu przykleić ją taśmą do górnej lub dolnej części w tym samym miejscu. Odkryliśmy jednak skuteczniejszą metodę, która działa nieco wydajniej i zapewnia lepsze wyniki ogrzewania.
Aby osiągnąć optymalne umiejscowienie, należy umieścić czujnik około sześciu cali w macie. Po zidentyfikowaniu tej lokalizacji upewnij się, że głowica czujnika jest prawidłowo ustawiona. Zalecamy zaznaczenie tego miejsca palcem dla odniesienia. Następnie należy wyjąć niewielką część wykładziny dywanowej, mniej więcej wielkości rogu, i sprawdzić, czy obszar ten znajduje się między jednym z dwóch przebiegów kabla. W tym momencie masz dwie opcje: możesz umieścić głowicę czujnika bezpośrednio w utworzonym otworze lub, jeśli jesteś blisko krawędzi ściany, możesz włożyć czujnik i poprowadzić kabel pod podkładką.
Jeśli zdecydujesz się poprowadzić kabel pod podkładką, możesz zabezpieczyć go taśmą, gdy wchodzi do otworu. Dodatkowo, użycie kawałka taśmy do przytrzymania czujnika na miejscu zapewni, że po ułożeniu maty będzie ona prawidłowo spoczywać na środku wyznaczonego obszaru. Gdy wszystko zostanie ustawione, możesz przeciągnąć dywan przez tę sekcję, mając pewność, że uzyskasz dokładny odczyt temperatury w tym miejscu.
