Programmable Timer Towel Warmer Control


Part Number: CO-TI-PLS750
This support page provides publications, manuals, specifications, support articles, and common support questions


question-mark
Common Support Questions (10)

publication
Publications and Manuals (5)

specifications
Specifications (12)

Articles (2)

Create a new Support Request

Common Support Questions


Briefly press the main button to turn the switch on/off.

Need more help? View support options

The LED in lower right corner of the thermostat will illuminate.

Need more help? View support options

Press the main button for 3 seconds, select the mode menu, the hand icon indicates manual operation and the clock icon indicates automatic operation.

Need more help? View support options

Change the 'state' by pressing the main button briefly. The load state will flash 'On' or 'Off' to indicate the change and will remain in effect until the next program cycle is invoked or the main button is pressed again.

Need more help? View support options

21 "on" programs and 21 "off" programs.

Need more help? View support options

Within 2 seconds, press the left button twice then press the right button twice.

Need more help? View support options

By default the Programable Timer is set to +45 longitude and -75 latitude, this is fine for most North American cities. To find your cities coordinates, go to www.geonames.org, or simply use a GPS device.
Note: enter a negative number for a south latitude or a west longitude.

Need more help? View support options

The ambient room temperature is either too low or too high, affecting the thermostat's display.

Need more help? View support options

Press and hold the main button for the Menu option, select Prog.  Press and release the main button until the days of the week are flashing.  Use the right arrow to scroll through the days of the week until you get the word NONE.  This means there will be no schedule for that specific program.

Need more help? View support options

Yes, regular (non-dimming) light switch can be used as an external switch to control a towel warmer in addition to a built-in switch on the towel warmer itself. A GFCI breaker powering the switch may be required by local Electrical Code.

Need more help? View support options


Publications and Manuals



Specifications


Electrical

Connection Single Pole or 3-Way
Connection Method Hardwired
Maximum Current 15 A
Maximum Load (Resistive Only) 1800 W
Supply 120 VAC, 60Hz
Voltage 120 VAC

Product Dimensions

Depth 1“
Length 3“
Weight 0.375 lbs
Width 2“

Identifiers

SKU CO-TI-PLS750
UPC (GTIN-12) 881308047542
