Tech Tips: How To Test Snow Melting Mats and Slab Heating Cable
Expert Testing Tips for Snow Melt Systems & Cables
Ever installed a heating system only to find it faulty after it's been buried? Avoid such costly mistakes with our essential testing guide.
This video empowers you with the knowledge to test your snow melting and slab heating systems, ensuring they work perfectly from the get-go. Not only can this save you money on potential repairs, but it also guarantees an uninterrupted heating experience.
We’ll guide you through each step, ensuring your system’s integrity:
- 💡 Learn the importance of testing cables and mats before, during, and after installation.
- ✅ Discover how to use a modern electronic Mega ohmmeter for accurate testing.
- ⚡ Understand testing differences between 120-volt and 240-volt systems.
- 📏 Master how to interpret ohmmeter readings for precise diagnostics.
By following these expert techniques, you’ll unlock the full potential of your heating system, providing you with warmth, comfort, and efficiency for years to come. Don't leave your heating systems to chance; ensure they’re operating at peak performance today!
Transcript
Hello. Whenever you order snow melt or slab heating cable, it is essential to test each cable or mat to ensure that it is in good condition before it gets buried in the concrete. The last thing you want is to install a mat that has been damaged during shipping, only to discover that it doesn't work when you turn it on. To test these mats, rolls, or cables, you will need a Mega ohmmeter.
There are two types of Mega ohmmeters: the old-fashioned hand-crank version, which we do not recommend using anymore, and the more modern electronic Mega ohmmeter. Each roll or cable that you incorporate into the system must be tested with a Mega ohmmeter. If you do not have one, you can rent a Mega ohmmeter from WarmlyYours or find one locally, as many electricians typically have them on hand.
A Mega ohmmeter tests the insulation between one of the electricity-carrying wires inside the system and ground. For example, if you are testing a 120-volt system, you will see one wire is yellow and the other is black. In a 240-volt system, the wires would be red and black. To conduct the test, you will measure from the yellow wire to ground and then from the black wire to ground, ensuring that the current-carrying wires are not making contact with the ground anywhere in the mat or cable.
To perform the test, attach the black clamp to the ground and set the Mega ohmmeter to 500 volts. Then, take the yellow wire and test it against the ground. If the reading shows infinity, that indicates that there is no contact between the current-carrying wire and the ground, which is a positive result.
Next, you will test the black wire, which may be difficult to see if it is behind the clamp. Press and hold the test button again at 500 volts. It is crucial to remember that this is a dangerous amount of current flowing through the wire, so do not touch the wires during the test. If you again receive an infinity reading, this confirms that there is no continuity between the black conductor and ground throughout the mat or cable.
Each mat or cable should be tested in this manner before, during, and after installation to ensure that nothing has compromised it. If everything goes well when you hook it up, your system will work effectively. Thank you for watching.
