TempZone™ Custom Mats Electric Custom Mats for Heated Floors

TempZone™ Custom Mats for tile, stone or hardwood floors were designed to offer the most optimal fit for rooms of any shape. Our custom-fit mats were developed to follow curves and angles with ease. These heated floor mats are ideal for bathrooms, kitchens and other areas in the home with permanent fixtures, solid structural elements or a non-standard room shape.

Request a Quote
Request a Free Product Sample
Support Page
  • Maximum Coverage Full coverage for any size space, such as bathrooms, kitchens, living rooms, or basements.
  • Easy to Install Easiest installation, no cut and turns required.
  • Clean Heat Doesn't disturb pollen, dust or other allergens like forced-air systems.
  • Safe ETL listed

Description

Our recently upgraded custom-sized electric heating mats arrive in one piece, making for a fast, simple installation — you don't have to make any cuts or trims. TempZone™ Custom Mats are commonly used beneath tile or stone flooring. These floor mats provide 12-15 watts/sq. ft., depending on the room size, and evenly distribute heat for full room coverage.

The mats feature a layered construction with the heating element sandwiched between two durable layers of fabric. WarmlyYours will help you design the perfect floor-heating system with free overnight design services. Each custom mat is made to order and is non-refundable.

Please allow for at least 8 to 10 business days after the point of purchase for this customized item to ship.

Learn more about electric floor heating systems

Example Project

This is a real example of a floor plan that uses this product. If you want to design your own room or have any questions, please contact us.

TempZone Custom Mat SmartPlan
Design Your Own Project Get a Free Quote
Flooring
Tile, Marble or Stone Subfloor
Wood
Room Type
Bathroom
Coverage
100%
Price
$729.00 MSRP (USD)
Voltage
120 VAC
Wattage
376 Watts
Operating Cost
2 cents per hour

Controls & Accessories

nSpire touch UDG4-4999-WY Logo FRONT
Floor Heating Controls
Shop Now »
Underlayment Sample
Underlayment
Shop Now »
WarmlyYours Circuit Check Amazon
Circuit Check
Shop Now »
floor heating rough in kits
Electrical Rough-In Kits for Thermostats
Shop Now »

Frequently Asked Questions

Showing all 9 questions

No, TempZone™ Custom Mats provide the easiest installation with no cut and turns required as they are specifically designed and built based on the dimensions of your project that you've provided to us. Prior to installation, dry-fit your mat to make sure it fits correctly. If there are any issues, call WarmlyYours at 1-800-875-5285.

1 person found this helpful Was this helpful? Yes No

The mats provide between 12 and 15 watts per sq. ft. (depending on room size). They are designed to distribute heat evenly for full room coverage.

1 person found this helpful Was this helpful? Yes No

TempZone Custom Mats are designed for installation under tile, natural stone, and nailed hardwood floors. The heating cable must be fully embedded in modified thinset or self-leveling underlayment before the final flooring is installed to ensure proper heat distribution and protection.

Was this helpful? Yes No

TempZone Custom Mats feature a cold lead that connects directly to your thermostat. The mat must be wired to a dedicated circuit. Multiple mats can be wired in parallel to a single thermostat, provided the total amperage does not exceed the thermostat’s limit (typically 15 amps). Always consult a licensed electrician and refer to the wiring diagram.

Was this helpful? Yes No

A TempZone Custom Mat is specifically manufactured to fit the exact dimensions and layout of your room. Unlike standard rectangular mats that require cutting and turning the mesh during installation, a Custom Mat rolls out in one continuous piece, providing the easiest and fastest installation possible.

Was this helpful? Yes No

To order a TempZone Custom Mat, provide a detailed floor plan of your room, including exact dimensions and the locations of any permanent fixtures (like vanities, toilets, or tubs). You can submit your drawing online or send it to our team. We will then create a custom SmartPlan showing exactly how the mat will be manufactured to fit your space perfectly.

Was this helpful? Yes No

Once your custom SmartPlan is approved, it typically takes just 1 to 2 business days to manufacture your TempZone Custom Mat. After manufacturing is complete, the mat is shipped directly to your location, ensuring you can proceed with your floor heating installation without delay.

Was this helpful? Yes No

No, a TempZone Custom Mat cannot be cut or altered on-site. The heating cable is factory-installed and precisely spaced to fit the exact dimensions of your approved SmartPlan. Cutting the heating cable will damage the system and void the warranty. If your room dimensions change, please contact us immediately before installation.

Was this helpful? Yes No

While TempZone Custom Mats may have a slightly higher initial cost than standard rolls or mats, they often save money on installation. Because they are manufactured to fit your exact room dimensions, they require significantly less labor and time to install, making them a highly cost-effective option for complex layouts.

Was this helpful? Yes No
