Wire end fork terminal connector, 12-10 AWG
This support page provides publications, manuals, specifications, support articles, and common support questions
Common Support Questions
If I have extra cold lead wire, can I trim off what I don't need for my installation?
Yes. Unlike the heating cable for electric floor heating, the cold lead wires can be trimmed.
Need more help? View support options
How many square feet of floor heating can be connected to one thermostat?
One thermostat can control multiple heating mats/cables as long as all the heating elements are using less than 15 amps:
TempZone™ will cover aprx. 120 sq. ft. for 120V systems and 240 sq. ft. for 240V systems on one thermostat.
Environ™ will cover aprx. 150 sq. ft. for 120V systems and 300 sq. ft. for 240V systems on one thermostat.
Slab Heat will cover aprx. 90 sq. ft. for 120V systems and 180 sq. ft. for 240V systems on one thermostat.
Need more help? View support options
Publications and Manuals
Specifications
Identifiers
| SKU | FHE-ROUGH-IN-TRM |
Warranty / Certifications
| Warranty | 10 Year Warranty under Laminate & Floating Hardwood, 5 Year under Carpet (US Only) |
Product Dimensions
| Weight | 1 lbs |
