Specifications

Electrical (TW-MT-10PS-HW)

Amps	1.25 A
Connection Method	Hardwired
Ingress Protection (IPxx) Rating	IP44
Ohms	96 Ω
On/Off Switch	Yes
Thermal Power	0.15 kW
Voltage	120 V
Watts	150 W

Warranty / Certifications (TW-MT-10PS-HW)

Approvals	cULus listed
ETL Listing Number	5008694
Warranty	2 years

Performance (TW-MT-10PS-HW)

Average Surface Temperature	149°F / 65°C
BTU Per Hour	512 Btu
Heat-up Time	15-20 minutes
TempSmart Safety Limit	149°F - 167°F / 65°C - 75°C
Towel Capacity	1-2

Product Dimensions (TW-MT-10PS-HW)

Bar Thickness (Radius)	0.5″
Depth	4¾″
Height	41½″
Mounting Footprint	18 ½“ (470mm) W x 28 ¾“ (730mm) H
Weight	12.4 lbs
Width	19¾″

Battery (GK16-30090-0002-A)

Battery Backup

Built-in rechargeable battery preserves date and time for up to 72 hours during a power outage; duration varies with battery age and use.

Installation (GK16-30090-0002-A)

Circuit Type	Single Pole / Multi-Location with Companion
Indoor Outdoor Usage	Indoor
Mounting Type	Wall Mount
Multi Location Companions	Leviton VP0SR switch companion for 3-way or additional locations
Neutral Wire Required	Yes
Terminal Type	Wire Leads

Appearance (0099-30870-0002)

Color

White

Electrical (GK16-30090-0002-A)

Connection Method	Hardwired
Frequency	60 Hz
Load Ratings	120 V AC: 15 A resistive/inductive; 600 W LED/CFL; 1800 W incandescent/halogen; 15 A fluorescent ballast; 1 HP motor.
Maximum Load Resistive Only	15 A
Power Source Type	Corded Electric
Standby Power	Less than 1 W
Voltage	120 V

Product Dimensions (GK16-30090-0002-A)

Control Body Dimensions	4.13 × 1.75 × 1.40 in (height × width × depth), excludes wallplate
Weight	0.4 lbs

Control (GK16-30090-0002-A)

Control Manufacturer	Leviton
Display Type	Backlit LCD with timer settings at-a-glance; green locator LED
Manufacturer Control Model	VPT24-1PZ
Operation Mode	ON-OFF
Programmable On Off Events	49
Schedule Memory	Programmable options and schedules retained until factory reset
Scheduling Features	Individual weekdays, weekends or day combinations; astronomical sunrise/sunset adjustment; optional automatic daylight-saving adjustment; randomized on/off mode
Switch Type	Push Button
Timer Type	24-hour programmable astronomical timer

Appearance (TW-MT-10PS-HW)

Cord Color	White
Finish	Polished Stainless Steel
Finish Application	None (bare steel)
Mounting Method	Wall Mounted
Steel Type	304-stainless steel
Style	Modern

Environmental (GK16-30090-0002-A)

Lower Temperature Rating	0 °C
Operating Humidity	0–90% RH, non-condensing
Upper Temperature Rating	40 °C

Warranty (GK16-30090-0002-A)

Manufacturer Warranty

5-year limited manufacturer warranty

Logistics (TW-MT-10PS-HW)

Package Contents

Towel Warmer, installation manual and hardware kit

Identifiers (TW-MT-10PS-HW)

SKU	TW-MT-10PS-HW
Towel Warmer Collection Name	Classic Collection
UPC (GTIN-12)	881308057732

Identifiers (GK16-30090-0002-A)

SKU	GK16-30090-0002-A

Identifiers (0099-30870-0002)

SKU	0099-30870-0002
UPC (GTIN-12)	881308071844

Certifications (GK16-30090-0002-A)

Specification Met

UL/CSA; cCSAus

Product Dimensions (0099-30870-0002)

Weight

0.05 lbs

Connectivity (0099-30870-0002)

Wi-Fi IEEE Standards	802.11 a/b/g/n
Wi-Fi Radio Frequency Bands	2.4 GHz
