PRO-Tect: Pipe Freeze Protection Economy Control with GFEP


Part Number: PT-ECONOMY
This support page provides publications, manuals, specifications, videos, support articles, and common support questions


question-mark
Common Support Questions (5)

publication
Publications and Manuals (4)

specifications
Specifications (18)

Videos (1)

Articles (1)

Related Items (10)

Similar Items (3)

Create a new Support Request

Shop Now

Common Support Questions


Yes, you can extend the sensor up to 2,000 ft. cable for enhanced installation options

Need more help? View support options

The blue LED lit solid indicates when the temperature falls to 32 °F (0 °C) for all set-points except the 30 °F (-1.1 °C) set-point. For the 30 °F (-1.1 °C) set-point the LOW TEMP alarm will indicate when the temperature drops to 28 °F (-2.2 °C).

Need more help? View support options

No, the FPT-130 (PT-Economy) is meant to be used with only the supplied thermistor sensor.

Need more help? View support options

  • Hold down the red TEST/RESET pushbutton for approximately ten seconds.

      - After the first five seconds the unit will go into Manual Mode, energizing the heater cable if it is not all ready energized.

      – After the second five seconds the unit will enter the LOW TEMP blue LED edit mode. This is indicated by the blue LED flashing rapidly. Release the button at this point. (The unit will exit Manual Mode.).

          Note: The blue LED may flash for a couple of seconds after releasing the red TEST/RESET pushbutton.

          • The blue LED will indicate whether the LOW TEMP Alarm is currently disabled or not.

                – If the blue LED remains on the LOW TEMP Alarm is currently enabled.

                – If the blue LED goes off the LOW TEMP Alarm is currently disabled.

                – To keep the setting as it is wait five seconds and the unit will resume normal operation.

                – To change this setting press the red TEST/RESET pushbutton within five seconds. The new status of this setting will show for three seconds before the unit resumes normal operation.

                     Note: The blue LED will flash rapidly before exiting the LOW TEMP blue LED editing mode and resuming normal operation.

          Need more help? View support options

          • POWER indicator – This green LED lit solid indicates that the FPT 130 (PT Economy) is receiving power.

                – Blinking indicates a calibration error.

          • HEAT indicator – This yellow LED lit solid indicates when the heater is energized.

                – Blinking asymmetric (1/2 sec off × 1–1/2 sec on) : Low Current Alarm, heater relay closed.

                – Blinking asymmetric (1/2 sec on × 1–1/2 sec off) : Low Current Alarm, heater relay open.

                – Blinking fast : Stuck relay.

          • LOW TEMP indicator – This blue LED lit solid indicates when the temperature falls to 32 °F (0 °C) for all set-points except the 30 °F (-1.1 °C) set-point. For the 30 °F (-1.1 °C) set-point the LOW TEMP alarm will indicate when the temperature drops to 28 °F (-2.2 °C).

                – Blinking indicates sensor fault.

                – Blinking fast indicates High Temperature alarm.

          • ALARM indicator – This red LED lit solid indicates when there is a high ground fault current.

                – Blinking indicates a GFEP circuit failure (this light will also blink while system is performing a self–test).

          Need more help? View support options


          Publications and Manuals



          Specifications


          Electrical

          Activation Temperature 30 F°, 38 F°, 45 F°, 50 F°
          Connection Method Hardwired
          Ground Fault Equipment Protection (GFEP) Self-test GFEP 30mA
          Maximum Load (Resistive Only) 30 A
          Voltage 100 - 277 VAC

          Warranty / Certifications

          Approvals UL and CSA listed
          Area of Use Non-hazardous locations
          Ingress Protection (IPxx) Rating IP66
          Warranty 2 years
          Waterproofing NEMA 4X

          Product Dimensions

          Depth 4.375 in
          Height 5.5 in
          Installed Depth 0.75 in
          Weight 2.7 lbs
          Width 8.125 in

          Thermostat

          Included Sensor 100k ohms, 20' lead

          Identifiers

          SKU PT-ECONOMY
          UPC (GTIN-12) 881308057169
