TempZone™ Flex Roll 240V 1.5′ x 76′, 114 sq.ft., 7.2A


TempZone™ Flex Roll 240V 1.5′ x 76′, 114 sq.ft., 7.2A




Get an Instant Quote
Request a Free Product Sample
Support Page

Features

  • 25 Year Warranty

  • 15 Watts Per Sq. Ft

  • 1/8'' Super thin rolls or mats to fit any room shape

TempZone™ Flex Rolls Description

Ideal for installation under tile, stone, marble, and nailed hardwood floors, TempZone™ Flex Rolls add radiant warmth and comfort to any room. These easy-to-install rolls are C-UL-US Listed and produce 15 watts per square foot, making them the hottest product on the market. The TempZone™ Flex Rolls feature a low-profile, 1/8", heating cable affixed to a mesh fabric backing in a serpentine pattern to evenly distribute heat over the entire floor.

Each cut-and-turn roll is 1.5 x 76 ft., providing of coverage. The 240 V TempZone™ Flex Rolls are backed by our unbeatable 25-year No Nonsense Warranty.

Specifications

Electrical

Amps 7.13 A
Floor Load 1.71 kW
Ohms 33.68 Ω
Ohms Per Ft 0.076 Ohm/ft
Thermal Power 1.71 kW
VOP 62
Voltage 240 V
Watts 1710 W
Watts Per Sq. Ft. 15 Watts Per Sq. Ft.

Warranty / Certifications

Approvals cULus listed
Warranty 25 Year Warranty
Wet Location Listed US, Canada

Performance

BTU Per Hour 5835 Btu

Product Dimensions

Cold Lead Length 15′
Coverage 114 ft²
Heating Cable Length 442.75′
Heating Element Thickness 1/8″
Length 76′
Weight 11 lbs
Width 1′ 6″

Appearance

Color Green

Logistics

Country of Origin (COO) India

Installation

Floor Types Commonly installed beneath tile and stone

Identifiers

SKU TRT240-1.5x76
UPC (GTIN-12) 881308021535

Installation Plans

This is a real example of an installation plan that uses this product. If you want to design your own room or have any questions, please contact us.

Customer Questions & Answers

TempZone™ Flex Rolls has 83 Questions and Answers.

Don't see the answer you're looking for? Post your question

How do I work with my electrician to install WarmlyYours electric floor heating?

While WarmlyYours electric radiant floor heating systems are typically installed by your floor covering contractor, a licensed electrician is recommended for the final thermostat hook-up. With every quote, we provide an Installation Plan layout, together with an electrical plan that has all the info required for the electrician.

35 people found this helpful.  Did you find this helpful? Yes No

How can I determine what I need for my floor heating project and how can I find out what my floor heating system will cost?

You can use the Instant Quote Tool, which gives you many options for your floor heating coverage. Use this interactive tool to design your room online and receive an instant quotation with product recommendations, rough-in and installation kits, cost of your control, etc. Planning your floor heating project is made easy when using our Instant Quote Tool.

Send us your floor plan or fax it to (800) 408-1100 and we will send you a quote, product recommendation and a free custom installation plan for your project.

29 people found this helpful.  Did you find this helpful? Yes No

Is electric floor heating safe and what about EMF?

Our electric radiant floor heating systems have withstood rigorous safety testing and earned the UL listing. They produce much less EMF than common household appliances like your TV or vacuum cleaner. The EPRI (Electric Power Research Institute) tests all electrical devices and publishes the data. Many common household appliances are tested at a distance of 6 inches. The test results indicate that on average, the EMF emitted for the following appliances, measured in Milligauss (mG) units, is:

Vacuum Cleaner: 300 mG

Microwave: 200 mG

Portable Heater: 100 mG

Dishwasher: 20 mG

Washing Machine: 20 mG

WarmlyYours TempZone™ (Twin): 1.8 mG

27 people found this helpful.  Did you find this helpful? Yes No

What voltage does WarmlyYours floor heating systems utilize?

The floor heating systems are offered in both 120 volt and 240 volt for the North American market. A 208 volt breaker panel can also accommodate our 240 volt floor heating system. It is important to note that the energy consumption will be the same: a 240 volt system will not cost more to operate than a 120 volt system. You are billed in kilowatts, and the 120 volt and 240 volt systems use the same amount of kilowatts. WarmlyYours often specifies a 120 volt system in smaller projects while a 240 volt system is typically recommended for larger projects (120 square feet of electric floor heating coverage or more). The benefit of switching to a 240 volt system is the reduction in amperage. Our programmable thermostat can control a radiant floor system up to 15 amps. The 120 volt system will reach 15 amps at 120 square feet of electric floor heating coverage. However, the 240 volt system will reach 15 amps at 240 square feet of electric floor heating coverage, allowing a much larger system to be connected to the thermostat. For installations over 240 square feet, a relay contactor or power modules are needed.

22 people found this helpful.  Did you find this helpful? Yes No

What type of flooring can I install along with an electric floor heating system?

WarmlyYours’ TempZone™ product is most commonly installed under tile, stone, and marble flooring, but can also be installed under many other popular floor covering options such as hardwood, vinyl and linoleum. We also have our Environ system, which is an electric floor heating product as well and is specially designed for installation under carpet (in the U.S. only), laminate and floating wood. WarmlyYours can accommodate any flooring type with either of the electric radiant floor heating products that we offer. If your flooring type isn't listed here, just give us a call at (800) 875-5285 and we will be happy to discuss it with you.

24 people found this helpful.  Did you find this helpful? Yes No

View all 83 Questions and Answers
