Repair/Splice Kit (Twin Conductor)
- Repair kit for damaged TempZone twin-conductor floor-heating cable.
- For compatible TempZone Flex Rolls, Easy Mats and 3.7 W/ft heating cable.
- Includes adhesive-lined heat shrink, two sealed crimp/solder connectors and one uninsulated butt connector.
- Not for extensions, terminations or altering heating-cable length.
Description
This splice kit is used to repair a damaged section of WarmlyYours TempZone twin-conductor floor heating cable. This can be used for twin-conductor TempZone Flex Rolls, TempZone Easy Mats, or TempZone 3.7-watt Floor Heating Cable. This kit includes: 1 flexible adhesive-lined heat shrink tube, 2 sealed crimp & solder connectors, and 1 uninsulated butt connector. Please note that this kit is not to be used for creating extensions, terminations, or for altering the length of the heating cable.
Specifications
Electrical
| Compatible Products | Any TempZone twin-conductor heating elements |
Product Dimensions
| Length | 3″ |
| Weight | 0.5 lbs |
| Width | 2½″ |
Logistics
| Package Contents | 1 flexible adhesive-lined heat shrink tube, 2 sealed crimp & solder connectors, and 1 uninsulated butt connector |
Identifiers
| SKU | SP-TWIN |
| UPC (GTIN-12) | 881308021283 |
Documents
Technical Information
Frequently Asked Questions
Showing all 1 questions
Please keep in mind that you must check your electric floor heating system with a digital ohmmeter in conjunction with a Circuit Check™. Take an initial reading as soon as you take the product out of the box to verify that it is within -5% / +10% of the values stated on the product’s label. This will give you a basis of comparison for future readings. Take a second reading once you have positioned the system to match your custom installation plan. It is also advisable to take an additional reading in the middle of the tile installation, just to make sure that the Circuit Check™ is doing its job. Then, take a final reading when you are finished with the floor installation and are ready to hook up the thermostat.
The Circuit Check™ is a tool developed by WarmlyYours to give you peace of mind and ensure trouble-free installations. Simply hook up the cold leads to the tool while you position the system to match your custom installation plan.
The Circuit Check™ will continuously monitor the continuity of the circuit during the installation of your system and during the installation of your flooring. The Circuit Check™ beeps immediately when a short in the system is detected, alerting you to a potentially damaged cable in the area you are working, before you lay the tile over the electric floor heating system. The WarmlyYours technical support team is available 24/7 to provide assistance if the alarm sounds, or if you would have any questions during your installation.
