PRO-Tect: Pipe Freeze Protection Dual-Zone Control with GFEP

5.00
Based on 1 review



Support Page

Features

  • Available max power outputs: 5W per linear ft., 8W per linear ft., and 10W per linear ft

  • Options for 120, 208, 240, and 277 voltages

  • Automatically varies wattage for optimal energy savings

  • Can be overlapped or criss-crossed

  • Safe: cUlus Listed and cCsaus Listed

Description

The PT-DUAL is a control that can be used with WarmlyYours PRO-Tect: Pipe Freeze Protection Self-Regulating Heating Cable for most commercial (non-hazardous) and residential applications that require 2 independent heater-control circuits. This control can be used for pipe freeze protection or process heating applications. Because this control comes with 2 temperature sensors and 2 built-in relays, it can independently or jointly control 2 resistive loads of up to 30-amps apiece.  Another added benefit of this control is that the integrated Ground Fault Equipment Protection (GFEP) in each of the heating circuits eliminates the need for GFEP protection in a circuit panel, which can significantly save on cost. The temperature set-points for the control are adjustable from −99.9 °F to 999 °F (note: please confirm the separate temperature rating of the heating element/s you use with the control) though the included sensors have an operating range of −40 °F to 230 °F. There are 2 temperature sensor inputs and the heating circuits can operate independently or from 1 sensor.

Features:
  • Compatible Voltages: 100 – 277 VAC
  • Load Rating for Each Heating Circuit: 30-amps
  • Included Temperature Sensors: 2 sensors (100k ohms) with 20’ lead-length
  • Ground Fault Equipment Protection (GFEP): Self-test GFEP for both heating Circ
  • Outdoor Rating: NEMA 4X waterproofing
  • Ingress Protection Rating: IP66
  • Area of Use: Nonhazardous Locations
  • Warranty: 2 years
  • Certifications: UL and CSA listed


Specifications

Electrical

Activation Temperature -99.9 to 999 °F
Connection Method Hardwired
Ground Fault Equipment Protection (GFEP) Self-test GFEP (Adjustable 1-300mA)
Maximum Load (Resistive Only) 2 x 30 A
Voltage 100 - 277 VAC

Warranty / Certifications

Approvals UL and CSA listed
Area of Use Non-hazardous locations
Ingress Protection (IPxx) Rating IP66
Warranty 2 years
Waterproofing NEMA 4X

Product Dimensions

Depth 5.9″
Height 12.8″
Installed Depth 0.75″
Weight 5.8 lbs
Width 9″

Thermostat

Included Sensor 2 x 100k ohms, 20' lead

Identifiers

SKU PT-DUAL
UPC (GTIN-12) 881308058302
