Transformer 300VA 20sqft Q-Tran

Part Number: TR-300VA-Q
This support page provides publications, manuals, specifications, support articles, and common support questions

Common Support Questions (3)

Publications and Manuals (1)

Specifications (10)

Articles (1)

Related Items (1)

Similar Items (5)

Create a new Support Request

Common Support Questions

All thermostats are mandated at 42" height for handicap accessibility, most private residences are mounted at 52-60".

Need more help? View support options

Poor maintenance, overheating, insulation breakdown, and vermin damage are common causes.

Need more help? View support options

If your floor is not heating and your thermostat is functioning properly, test to see if proper voltages are present at the transformer.  If 24 VAC is not being returned by the transformer, then it either needs to be replaced or checked to ensure that the internal secondary circuit breakers have not been tripped and are functioning properly.  Contact Warmly Yours technical support at 1-800-875-5285 for further assistance.

Need more help? View support options

Publications and Manuals



Breaker Amperage 15 Amps
Connection Method Hardwired
Output Wattage 300 Watts
Power 120V
Voltage (Output) 24 VAC

Product Dimensions

Depth 5.75“
Height 8.63“
Width 3.1“


UPC (GTIN-12) 881308010669
