Snow Melt Aerial Sensor
Features
-
Detects falling or blowing snow at temperatures below 38°F (3.3 °C)
-
Provides a more robust sensor at less weight, lower visual profile and lower cost comparing to the previous generation
-
Sleeker profile provides a very aesthetically pleasing appearance
-
For the most versatile and effective snow detection, use with the SCP-120 Premium Snow Melt Control
-
This sensor is compatible with SC-MZ-TOUCH, SCA-DUAL, and SCP-120 snow melt controls
Snow Melting Sensors Description
The AIR-SS-2 Aerial-Mounted Snow Sensor provides versatile and cost-effective automatic snow detection for snow melting and roof and gutter deicing systems. Easy to install, the AIR-SS-2 Aerial-Mounted Snow Sensor is appropriate for use with the SC-MZ-TOUCH, SCP-120, and SCA-DUAL controls. It senses both ambient temperature and precipitation, detecting falling or blowing snow at temperatures below 38°F (3.3°C). The included 16-inch, 3-conductor, 18 AWG lead allows for flexibility of installation, allowing sensors to be located at a distance up to 500 feet away from the controller using 22-gauge wires and up to 1000 feet using 18 gauge wires.
Learn more about snow melting systems. Perfect for heated driveways, patios, walkways and paths, accessibility ramps, or even stairs.
Specifications
Electrical
| Accepted Voltage Frequency | 24 V |
| Activation Temperature | 38 °F |
| Lead Length | 16″ |
| Sensitivity | Temperature and precipitation |
Product Dimensions
| Depth | 1¾″ |
| Diameter | 1.75″ |
| Height | 3¾″ |
| Weight | 0.2 lbs |
| Width | 1¾″ |
Installation
| Installation Area | Aerial |
Identifiers
| SKU | AIR-SS-2 |
| UPC (GTIN-12) | 881308065485 |
Warranty / Certifications
| Warranty | 2 years |
Documents
Operation Manuals
- AIR-SS-2 Aerial Mounted Snow Sensor Manual (English)
- AIR-SS-2 Aerial Mounted Snow Sensor Manual (French)
Project Planners
- AIR-SS-2 Snow Sensor Checklist (English)
- WarmlyYours Snow Melting Field Pocket Guide - Quick Field Troubleshooting Checklist (English)
Technical Information
- AIR-SS-2 Specification Sheet (English)
- Sensor Placement for Snow and Ice Melt Applications (English)
Catalogs
Frequently Asked Questions
Showing all 4 questions
After installation the sensor can be tested by cooling the sensor base with either ice (do not immerse the sensor in ice water, it is not water proof) or freeze mist. Locate the internal temperature sensor by first locating the indexing tab (see page 5 of the manual) and apply the mist to the base of the sensor on the opposite side of the indexing tab.
Once the unit is cooled continue by placing a drop of water on the moisture grid. If testing in the winter and the temperature is below 38°F (3.3°C), then simply placing a drop of water or a small amount of snow on the moisture grid will start a heating cycle. To stop the cycles, simply turn off the power for 5 to 10 seconds and then turn it back on.
It depends on how the system is intended to operate. If the expectation is manual operation (ex. WiFi or Timer Control), then no sensors are required. If the expectation is automatic operation, then the system will require at least one snow sensor.
No, a sensor is not required with the snow melt system. However, certain automatic controllers require a temperature/moisture sensor to sense atmospheric conditions and may also require an in-slab, high temperature limit sensor to be installed (notably, asphalt installations).
