Bellagio Towel Warmer, Polished, Hardwired, 20 Bars


Part Number: TWS3-BLG20PH
This support page provides publications, manuals, specifications, videos, support articles, and common support questions


question-mark
Common Support Questions (5)

publication
Publications and Manuals (7)

specifications
Specifications (31)

Videos (6)

Articles (3)

Related Items (16)

Similar Items (1)

Create a new Support Request

Shop Now

Common Support Questions


Electric-resistance heating cables and systems have no polarity. This includes all current WarmlyYours heating elements.

Need more help? View support options

Test the ohms of the unit to verify that it is within 5-10% of the resistance indicated in specs. Verify that there is at least 110 volts present into and out of the power supply. If the ohms are too high, the warmer will feel cooler. The lower the voltage, the cooler the unit.If these values are within specs, the towel warmer is working as designed.

Need more help? View support options

If a warmer towel is desired, try folding the towel over or unfold it to experiment, try a thicker towel (traps more heat, resulting in higher surface temperatures), a different fabric (cotton vs. blends), leave the towel warmer on longer before the shower (thicker towel plus longer heating time), or place a second towel on the warmer to trap more heat. Keep in mind, the towel will at some point reach its maximum temperature on the towel rack. If that time is an hour, leaving the warmer on all day will not raise the maximum temperature of that towel or warmer, but if you would like to experiment, that's OK, too.

Need more help? View support options

If a towel cools off too soon after removing it from the warmer, try a differently-constructed towel. The warmer has NO affect on the heat loss of the particular towel after it is removed from the warmer.

Need more help? View support options

One can leave the towel warmer on all day. If doing so, observe the towels on the warmer every couple of hours the first day or two to verify that the towels do not become discolored or scorched by leaving the warmer on all day.

Need more help? View support options


Publications and Manuals



Specifications


Electrical

Amps 1.58 A
Connection Method Hardwired
Ingress Protection (IPxx) Rating IP55
Ohms 75.79 Ohm
On/Off Switch Yes
Voltage 120 VAC
Watts 190 W

Warranty / Certifications

Approvals cULus listed
Warranty 5-year limited warranty

Performance

Average Surface Temperature 122°F / 50°C
BTU Per Hour 648
Heat-up Time 15-20 minutes
TempSmart Safety Limit 149°F - 167°F / 65°C - 75°C
Towel Capacity 1-3

Appearance

Bar Arrangement Groups of 4, 4, 5, and 7 bars
Bar Shape Round
Bar Spacing 1.25″ and 3.25″
Finish Polished
Mounting Method Wall Mounted
Steel Type 304-stainless steel
Style Classic
Towel Bars 20-bars

Product Dimensions

Depth 4.3 in
Height 47.2 in
Mounting Footprint 18 ¾“ (476mm) W x 40 ¼“ (1022mm) H
Weight 14.4 lbs
Width 20 in

Logistics

Package Contents Towel Warmer, installation manual and hardware kit

Identifiers

SKU TWS3-BLG20PH
Towel Warmer Collection Name Classic Collection
UPC (GTIN-12) 881308054939
