Snow and Ice Melting Control Premium
- Voltage: 120/240 VAC; 50/60 hz, 24A
- Features NEMA 3R enclosure
- Supports up to 6 sensors (aerial, gutter, or pavement)
- Automatic and manual override operator controls
- 2-year warranty
Premium Snow & Ice Melt Control Description
The SCP-120 premium, automatic snow/ice melting control provides for easy installation and operation to minimize energy use. For use with WarmlyYours snow melting or roof and gutter deicing systems, it operates electrically- and mechanically-held contactors for pilot duty applications.
The SCP-120 Premium Snow Melt Control includes an OT-Sensor (for use as an additional slab temperature sensor) and features a NEMA 3R wall-mounted enclosure (recommended for indoor installation). With an Energy Management Computer (EMC) interface and heater hold-on and test capabilities, the unit is rated for 120/240 VAC and supports up to six sensors (aerial, gutter, or pavement). cULus Listed for use in Canada and the U.S.
The maximum load for this control is 24 Amps. We do recommend that it is used in conjunction with a compatible relay panel.
Learn more about snow melting systems. Perfect for heated driveways, patios, walkways and paths, accessibility ramps, or even stairs.
Specifications
Warranty / Certifications
| Approvals | cULus listed |
| Area of Use | Non-hazardous locations |
| Warranty | 2 years |
| Waterproofing | NEMA 3R |
Installation
| Best Use | Best For Asphalt Projects |
Electrical
| Compatible Sensors and Accessories | RCO, AIR-SS, AIR-SS-2, GTR-SS, SC-SS-PAV-6E-KIT |
| Connection Method | Hardwired |
| Control Options | Automatic with manual override |
| Max Number of Sensors | 6 |
| Maximum Current | 24 A |
| Mounting Method | Wall Mounted |
| Voltage | 120/240 V |
Product Dimensions
| Depth | 6.562 in / 167 mm |
| Height | 9.125 in / 232 mm |
| Weight | 9 lbs |
| Width | 11.5 in / 292 mm |
Identifiers
| SKU | SCP-120 |
| UPC (GTIN-12) | 881308020613 |
Accessories and Parts
Feel free to chat us if you have any questions about these items.
Documents
Installation
- Retrofit Snow Melting System Application Guide (English)
- Snow Melting Application Cross Sections (English)
Operation Manuals
Project Planners
Technical Information
- Sensor Placement for Snow and Ice Melt Applications (English)
- Snow Melting RCO Specifications (English)
Wiring Diagrams
Sell Sheets
- Premium SCP-120 Snow Melt Control Sell/Specs Sheet (English)
- Snow Melt Controller Comparison Sheet USA (English)
Catalogs
Frequently Asked Questions
Showing all 5 questions
GFEP is the National Electric Code (NEC) required protection for fixed outdoor deicing and snow-melting equipment, which may be accomplished by using circuit breakers equipped with ground-fault equipment protection (GFEP) of 30 mA. It is important to understand that this required equipment protection is NOT the same as a 5 mA GFCI used for personal protection.
It depends on how the system is intended to operate. If the expectation is manual operation (ex. WiFi or Timer Control), then no sensors are required. If the expectation is automatic operation, then the system will require at least one snow sensor.
