Snow and Ice Melting Control Premium

$2,099
  • Voltage: 120 VAC; 50/60 Hz, 24A
  • Features NEMA 3R enclosure
  • Supports up to 6 sensors (aerial, gutter, or pavement)
  • Automatic and manual override operator controls
  • 2-year warranty
Need help? Call our experts at (800) 875-5285
Support Page
Jump to

Premium Snow & Ice Melt Control Description

TheSCP-120 premium, automatic snow/ice melting control provides for easyinstallation and operation to minimize energy use. For use with WarmlyYourssnow melting or roof and gutter deicing systems,it operateselectrically- and mechanically-held contactors for pilot duty applications.

TheSCP-120 Premium Snow Melt Control includes an OT-Sensor (for use as anadditional slab temperature sensor) and features a NEMA3R wall-mounted enclosure (recommended for indoor installation). With an Energy Management Computer (EMC) interface and heater hold-onand test capabilities, the unit is rated for 120 VAC and supports up to sixsensors (aerial, gutter, or pavement). cULus Listed for use in Canada and the U.S.

The maximum load for this control is 24 Amps. We do recommend that it is used in conjunction with a compatible relay panel.

Specifications

Warranty / Certifications

Approvals cULus listed
Area of Use Non-hazardous locations
Warranty 2 years
Waterproofing NEMA 3R

Installation

Best Use Best For Asphalt Projects

Electrical

Building Automation Interface Dry relay contacts: Override On and Override Off inputs; Supply, Snow, Heat and High Temperature outputs
Compatible Sensors and Accessories RCO, AIR-SS, AIR-SS-2, GTR-SS, SC-SS-PAV-6E-KIT
Connection Method Hardwired
Control Options Automatic with manual override
Max Number of Sensors 6
Max Sensor Wire Length 500 ft (152 m) with 18 AWG 3-wire jacketed cable
Maximum Current 24 A
Mounting Method Wall Mounted
Voltage 120 V

Product Dimensions

Depth 6.562 in / 167 mm
Height 9.125 in / 232 mm
Weight 9 lbs
Width 11.5 in / 292 mm

Construction

Operating Temperature Range -40°F to 160°F (-40°C to 71°C)

Logistics

Package Contents SCP-120 control panel (Qty 1), high-limit temperature sensor with 20′ lead (Qty 1)

Identifiers

SKU SCP-120
UPC (GTIN-12) 881308020613

Frequently Asked Questions

Showing all 5 questions

It can go outdoors provided weatherproof fittings are used.  The optional RCO switch should be considered for remote operation from an indoor location.

1 person found this helpful Was this helpful? Yes No

The AIR-SS-2 can be mounted at a distance up to 500 feet away from the controller using 22-gauge wires and up to 1000 feet using 18-gauge wires.

Was this helpful? Yes No

Our systems can handle low temperatures, but many controls come equipped with a Low-Temperature Lockout Feature. This feature prevents the system from running in very low temperatures. At very low temperatures it can become difficult for the system to effectively melt the snow. It is however possible to turn off this feature should you need the system to keep running during such low temperatures.

14 people found this helpful Was this helpful? Yes No

All of our automatic controllers have a Hold-on time feature after the initial warming up of the snow melt system. This feature ensures that all the snow is melted from the surface, and also that the system continues to operate and evaporate the surface water without it refreezing.

9 people found this helpful Was this helpful? Yes No

When the design requirement's amp draw exceeds the selected controller's capacity.

5 people found this helpful Was this helpful? Yes No
