nJoin Power Module, 15mA EGFPD ASG-4999
Part Number: ASG-4999
The nJoin is an intuitive Power Module with built-in GFCI for large electric floor heating applications. The nSpire Touch, nSpire Touch Wifi, nHance and nTrust thermostats can be extended with additional nJoin power modules. Output can be increased by 15 A per nJoin module.
This support page provides publications, manuals, specifications, videos, support articles, and common support questions
The nJoin is an intuitive Power Module with built-in GFCI for large electric floor heating applications. The nSpire Touch, nSpire Touch Wifi, nHance and nTrust thermostats can be extended with additional nJoin power modules. Output can be increased by 15 A per nJoin module.
This support page provides publications, manuals, specifications, videos, support articles, and common support questions
Common Support Questions (5)
Publications and Manuals (5)
Specifications (15)
Videos (2)
Articles (4)
Related Items (1)
Similar Items (1)
Create a new Support Request
Common Support Questions
Breaker and wire sizes are selected based on the total amperage of the heating system connected to a single thermostat. This information is on the heating product's installation plan, electrical plan, or UL label. Based on guidelines from the National Electrical Code: loads up to 16 Amps may utilize 12 gauge wire with a 20-Amp breaker, and loads up to 12 Amps - 14 gauge wire with a 15-Amp breaker. Local code and/or other factors may change these guidelines.
Need more help? View support options
Pressing and holding (2-3 sec) physical power/reset button will turn the unit completely OFF. Same process turns the unit back on.
(nHance and nJoin units will have the button on the front faceplate, nSpire Touch WiFi, nSpire Touch and nTrust will have the button on the right side of the faceplate.)
Need more help? View support options
Solution:
The ground wire in the floor mat must be connected directly to the ground wire of the supply or to the house ground wire.
Need more help? View support options
Solution:
Yes the adaptive function is reset during a factory reset.
Need more help? View support options
All thermostats are mandated at 42" height for handicap accessibility, most private residences are mounted at 52-60".
Please see this video on how to install a WarmlyYours nSpiration Series thermostat: https://www.warmlyyours.com/video-media/wire-nspiration-thermostat-to-electric-floor-heating-roll
Need more help? View support options
Publications and Manuals
Wiring Diagrams
nJoin (USG-4000) Wiring Diagram (English)Wiring Diagram for Multiple Twin Floor Heaters with nSpire Series Thermostat Using a Junction Box (English)
Specifications
Warranty / Certifications
| Approvals | cULus listed |
| Ingress Protection (IPxx) Rating | IP21 |
| Warranty | Limited 3-year warranty and lifetime technical support |
Electrical
| Connection | 4 wires, double pole |
| Connection Method | Hardwired |
| Ground Fault Protection | 15mA EGFPD |
| Maximum Current | 15A |
| Maximum Power | 1800 W @ 120 V, 3120 W @ 208 V, 3600 W @ 240 V |
| Supply | 120 VAC, 208 VAC, 240 VAC (50/60Hz) |
Logistics
| Country of Origin (COO) | Denmark |
Product Dimensions
| Depth | 2in |
| Installed Depth | 0.8125in |
| Length | 4.688″ |
| Width | 2.875″ |
Identifiers
| SKU | ASG-4999 |
